RFloXa Hawk36 Max Fork
RFloXa Hawk36 Max inverted e-moto fork with 228mm travel and 800mm length. Details below are as published by RFloXa and its US distributor.
Features and Specifications
① Heavy-Duty E-Moto Suspension Performance — This 228mm inverted fork is designed specifically for high-performance electric dirt bikes, delivering stable handling, strong impact absorption, and consistent control on aggressive trails, jumps, and mixed terrain riding. Built around Arctic Leopard XE PRO S specifications, it provides a factory-level fit and geometry match for 19” and 21” wheel setups.
② Inverted Oil-Spring Damping System — A precision-engineered inverted suspension design with oil-spring damping delivers smooth compression, controlled rebound, and improved front-end stability under hard braking, high-speed riding, and repeated impacts.
③ Reinforced CNC + Forged Construction — Built with AL6061-T6 forged aluminum lower brackets and AL7075-T6 fork tubes, paired with a MAX CNC precision-machined triple clamp interface for increased rigidity, durability, and long-term off-road reliability.
④ Multi-Stage Adjustability — Full tuning control with high-speed compression, low-speed compression, rebound damping, and spring preload adjustments allows riders to fine-tune performance based on rider weight, terrain, and riding style.
⑤ Long-Travel Impact Absorption — 228mm of main piston travel provides enhanced shock absorption for larger impacts, drops, and technical terrain, while maintaining front-end stability and predictable handling.
⑥ Optimized Brake & Fit Compatibility — Designed with a 90mm caliper mount spacing and support for up to 220mm disc brakes (upgradeable), ensuring strong braking performance for high-power electric dirt bikes.
Fitment
Arctic Leopard XE PRO S
Wheel Compatibility: 19” / 21”
Spring Weight Guide
45lb Spring: ≤85kg (≤187 lbs)
55lb Spring: 85–120kg (187–265 lbs)
45–60lb Progressive Spring: 80–130kg (176–286 lbs)
Specifications
Center Distance: 800mm
Main Piston Travel: 228mm
Tube Diameter: Ø37mm
Caliper Mount Spacing: 90mm
Disc Brake Size: Ø220mm (Upgradeable)
Damping System: Inverted Oil-Spring
Adjustments: High-Speed Compression, Low-Speed Compression, Rebound, Spring Preload
Materials:
AL6061-T6 Forged Aluminum Alloy Bottom Brackets
AL7075-T6 Aluminum Fork Tubes
Spring Wire: 55CRSI
Additional Note
Upper bearing is not pre-installed. Fork ships with standard configuration to ensure compatibility across multiple bike models and setups.
Available Options
- 45lbs 228mm Travel 800mm Length
- 50lbs 228mm Travel 800mm Length
